Ethernet 10 Ports Poe Media Conver10G uplink 52-port L2+ managed industrial PoE switch

L2+ managed industrial PoE fiber switch with 48* 10/100/1000M RJ45 ports and 4*1/10G SFP+ fiber slot ports, Port 1-48 can support IEEE 802.3af/at PoE standard, Built-in 600W power supply. Support 1U/19 inch rack installation.

EMAIL

Overview:

The ETP-IPS36048PFM is a 10G uplink managed industrial PoE fiber switch independently developed by Evertop.

It has 48*10/100/1000Base-T RJ45 ports and  4*1/10G SFP+ fiber slot ports. Port 1-48 can support IEEE 802.3af/at standard PoE power supply.

single port PoE power reaches 30W, and the maximum PoE output power is 600W. As a PoE power supply device, it can automatically detect and

recognize power-compliant devices that meet the standard and supply power through the network cable. It can supply power to POE terminal

equipment such as wireless AP, webcam, VoIP, industrial sensor through the network cable, and meet the network environment that needs high-density

 PoE power supply. It is suitable for intelligent transportation, rail transit, power industry, mining, petroleum, Industrial scenes such as shipping,

metallurgy, and green energy construction form a cost-effective, stable and reliable communication network.


The ETP-IPS36048PFM has the L2+ full network management function, supports IPV4/IPV6 management, supports static route full line rate

forwarding, supports complete security protection mechanism, complete ACL/QoS policy and rich VLAN functions, and is easy to manage and maintain.

Supports multiple network redundancy protocols STP/RSTP/MSTP (<50ms) and (ITU-T G.8032) ERPS to improve link backup and network reliability.

When one-way network fails, communication can be quickly restored to ensure important Uninterrupted communication for applications.

According to the actual application requirements, you can configure multiple application services such as PoE power management, port traffic control,

VLAN division, and SNMP through the Web network management mode

Feature:

Gigabit wire speed access, 10G uplink

◇ A combination of Gigabit Ethernet port and 10G uplink SFP+ port to meet the networking requirements of various scenarios.

◇ Support non-blocking wire-speed forwarding.

◇ Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.



Intelligent PoE power supply function

◇ 48*10/100/1000Base-T RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

◇ IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

◇ Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

◇ PoE network management, realize PoE port power allocation, priority setting, port power status viewing, time scheduling, etc.


Security

◇ 802.1X authentication.

◇ Port isolation,Storm control.

◇ IP-MAC-VLAN-Port binding.


Strong business processing capability

◇ IEEE802.1Q VLAN, flexible VLAN division,Voice VLAN and QinQ configuration.

◇ QoS, Priority mode based on 802.1P, Port & DSCP, queue scheduling algorithm including Equ, SP, WRR & SP+WRR.

◇ ALC, filter data packet through configuring matching rules, processing operation & time permission, and provide flexible and safe access control.

◇ IGMP V1/V2 and IGMP Snooping.

◇ ERPS/STP/RSTP/MSTP.

◇ Static and dynamic aggregation.


Stable and reliable

◇ CCC,CE, FCC, RoHS.

◇ Low power consumption, galvanized steel casing, The fan active cooling.

◇ The user-friendly panel, it can show the device status through the LED indicator of PWR, Link,PoE.

◇ Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.

 52-port 10G industrial PoE switch, industrial PoE switch, industrial switch

Easy operation and maintenance management

◇ HTTPS, SSLV3, and SSHV1/V2.

◇ RMON, system log, LLDP, and port traffic statistics.

◇ CPU monitoring, memory monitoring, Ping test, and cable diagnose.

◇ Web management, CLI command line (Console, Telnet), SNMP (V1/V2/V3).


DIMENSION


 52-port 10G industrial PoE switch, industrial PoE switch, industrial switch

ORDERING INFORMATION


Model

Description

ETP-IPS36048PFM

L2+ managed industrial PoE fiber switch with 48* 10/100/1000M RJ45 ports and 4*1/10G SFP+ fiber slot ports, Port 1-48 can support IEEE 802.3af/at PoE standard, Built-in 600W power supply. Support 1U/19 inch rack installation.

NoteIndustrial PoE switch does not match SFP module by default.



PACKING LIST


Packing List

CONTENT

QTY

UNIT

52-Port 10G uplink managed industrial PoE fiber switch

1

SET

RJ45-DB9 Line

1

PC

AC Power Cable

1

PC

Mounting Kits

1

SET

User Guide

1

PC

Warranty Card

1

PC
